DC gain accuracy (averaged), >20 GHz models
Instrument performance test Minimum Incoming Outgoing Maximum
Ch1 20 mV Vert scale setting,
0 V termination
0 Div position setting, 0 V offset
0 Div position setting, +1 V offset
0 Div position setting, -1 V offset
+1.5 V termination
0 Div position setting, +2.5 V offset
0 Div position setting, +1.5 V offset
0 Div position setting, +0.5 V offset
+3.4 V termination
0 Div position setting, +3.4 V offset
0 Div position setting, +2.4 V offset
-3.4 V termination
0 Div position setting, -3.4 V offset
0 Div position setting, -2.4 V offset
-1.5 V termination
0 Div position setting, -2.5 V offset
0 Div position setting, -1.5 V offset
0 Div position setting, -0.5 V offset
+ 117.6 mV
+ 117.6 mV
+ 117.6 mV
+ 117.6 mV
+ 117.6 mV
+ 117.6 mV
+ 117.6 mV
+ 117.6 mV
+ 117.6 mV
+ 117.6 mV
+ 117.6 mV
+ 117.6 mV
+ 117.6 mV
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
+ 122.4 mV
+ 122.4 mV
+ 122.4 mV
+ 122.4 mV
+ 122.4 mV
+ 122.4 mV
+ 122.4 mV
+ 122.4 mV
+ 122.4 mV
+ 122.4 mV
+ 122.4 mV
+ 122.4 mV
+ 122.4 mV
Ch1 50 mV Vert scale setting,
0 V termination
0 Div position setting, 0 V offset
0 Div position setting, +1 V offset
0 Div position setting, -1 V offset
+1.5 V termination
0 Div position setting, +2.5 V offset
0 Div position setting, +1.5 V offset
0 Div position setting, +0.5 V offset
+3.4 V termination
0 Div position setting, +3.4 V offset
0 Div position setting, +2.4 V offset
-3.4 V termination
0 Div position setting, -3.4 V offset
0 Div position setting, -2.4 V offset
-1.5 V termination
0 Div position setting, -2.5 V offset
0 Div position setting, -1.5 V offset
0 Div position setting, -0.5 V offset
+ 294 mV
+ 294 mV
+ 294 mV
+ 294 mV
+ 294 mV
+ 294 mV
+ 294 mV
+ 294 mV
+ 294 mV
+ 294 mV
+ 294 mV
+ 294 mV
+ 294 mV
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
__________
+ 306 mV
+ 306 mV
+ 306 mV
+ 306 mV
+ 306 mV
+ 306 mV
+ 306 mV
+ 306 mV
+ 306 mV
+ 306 mV
+ 306 mV
+ 306 mV
+ 306 mV
