Input resistance

Instrument performance test Minimum Incoming Outgoing Maximum

Input resistance, >20 GHz models

Ch1 6.25 mV/div

Ch2 6.25 mV/div

Ch3 6.25 mV/div

Ch4 6.25 mV/div

Ch1 140 mV/div

Ch2 140 mV/div

Ch3 140 mV/div

Ch4 140 mV/div

48.5 Ω

47.8 Ω

__________

51.5 Ω

52.2 Ω

Input resistance, ≥4 GHz, ≤20 GHz models

Ch1 10 mV/div

Ch1 100 mV/div

Ch2 10 mV/div

Ch2 100 mV/div

Ch3 10 mV/div

Ch3 100 mV/div

Ch4 10 mV/div

Ch4 100 mV/div

49.0 Ω

47.8 Ω

49.0 Ω

47.8 Ω

49.0 Ω

47.8 Ω

49.0 Ω

47.8 Ω

__________

51.0 Ω

52.2 Ω

51.0 Ω

52.2 Ω

51.0 Ω

52.2 Ω

51.0 Ω

52.2 Ω

TekProtect

Ch1 +2.2 V

Ch1 –2.2 V

Ch1 –65 mA

Ch2 +2.2 V

Ch2 –2.2 V

Ch2 –65 mA

Ch3 +2.2 V

Ch3 –2.2 V

Ch3 –65 mA

Ch4 +2.2 V

Ch4 –2.2 V

Ch4 –65 mA

–100 μA

–3.42 V

–100 μA

–3.42 V

–100 μA

–3.42 V

–100 μA

–3.42 V

__________

+100 μA

+3.42 V

+100 μA

+3.42 V

+100 μA

+3.42 V

+100 μA

+3.42 V

Time base system

Instrument performance test Minimum Incoming Outgoing Maximum

Long term sample rate, delay time, and internal

reference accuracy

10 MHz, <4 GHz models

10 MHz, ≥4 GHz models

9999.965 kHz

9999.975 kHz

__________

10000.035 kHz

10000.025 kHz

External reference

10 MHz

Pass/Fail

__________

Pass/Fail

Delta time measurement, <4 GHz models

DPO7054C only:

N/A

__________

6.0 ps

12.0 ps

Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)

MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 171
