Tektronix MSO70000C/DX

Scale setting Position setting
(Divs)
Offset setting
4
Generator setting Accuracy limits
50 mV -5 +0.25 V +650 mV +636.75 mV to +663.25 mV
+5 -0.25 V -650 mV -663.25 mV to -636.75 mV
100 mV -5 +2.0 V +2.8 V +2.764 V to 2.836 V
+5 -2.0 V -2.8 V -2.836 V to -2.764 V
200 mV -5 +1.25 V +2.75 V +2.697 V to 2.803 V
+5 -1.25 V -2.75 V -2.803 V to -2.697 V
500 mV -5 0 V +3.5 V +3.394 V to 3.606 V
+5 0 V -3.5 V -3.606 V to -3.394 V
< 4 GHz models, 50 Ω and 1 MΩ
1 mV -5 +0.5 V +507 mV +504.24 mV to +509.76 mV
+5 -0.5 V -507 mV -509.76 mV to -504.24 mV
2 mV -5 +0.5 V +516 mV +512.97 mV to +519.03 mV
+5 -0.5 V -516 mV -519.03 mV to -512.97 mV
5 mV -5 +0.5 V +540 mV +536.26 mV to +543.74 mV
+5 -0.5 V -540 mV -543.74 mV to -536.26 mV
10 mV -5 +0.5 V +580 mV +574.19 mV to +585.81 mV
+5 -0.5 V -580 mV -585.81 mV to -574.19 mV
20 mV -5 +0.5 V +660 mV +651.62 mV to +668.38 mV
+5 -0.5 V -660 mV -668.38 mV to -651.62 mV
50 mV -5 +0.5 V +900 mV +883.81 mV to +916.19 mV
+5 -0.5 V -900 mV -916.19 mV to -883.81 mV
90 mV -5 +0.5 V +1.22 V +1.192 V to +1.248 V
+5 -0.5 V -1.22 V -1.248 V to -1.192 V
100 mV 0 +4.5 V +4.8 V +4.746 V to +4.854 V
0 -4.5 V -4.8 V -4.854 V to -4.746 V
200 mV -2 +4.6 V +4.8 V +4.725 V to +4.875 V
+2 -4.6 V -4.8 V -4.875 V to -4.725 V
500 mV -2 +5.0 V +4.5 V +4.345 V to +4.655 V
+2 -5.0 V -4.5 V -4.655 V to -4.345 V
1 V 50 Ω 0 +2.0 V +5.0 V +4.742 V to +5.258 V
0 -2.0 V -5.0 V -5.258 V to -4.742 V
1 V 1 MΩ 0 +96.0 V +99.0 V +98.390 V to +99.610 V
0 -96.0 V -99.0 V -99.610 V to -98.390 V
d. Display the test signal:
■
From the button bar touch Vertical and touch Position.
4
Set as precisely as the instrument's offset resolution permits.
Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 185
