Tektronix MSO70000C/DX Technical Reference

Ch Scale
setting
Termination
setting
Position
setting
(Divs)
Offset
setting
Generat
or
setting
Measurement
mean
Difference of
measurement
means
Accuracy limits
-3.4 V 0 -3.4 V -3.381 V +37.24 mV to
+38.76 mV
-3.419 V
0 -2.4 V -2.381 V +37.24 mV to
+38.76 mV
-2.419 V
-1.5 V 0 -2.5 V -2.481 V +37.24 mV to
+38.76 mV
-2.519 V
0 -1.5 V -1.481 V +37.24 mV to
+38.76 mV
-1.519 V
0 -0.5 V -481 mV +37.24 mV to
+38.76 mV
-519 mV
Ch1 10 mV 0 V 0 0 V 30 mV +58.8 mV to
+61.2 mV
-30 mV
0 +1 V 1.03 V +58.8 mV to
+61.2 mV
970 mV
0 -1 V -970 mV +58.8 mV to
+61.2 mV
-1.03 V
1.5 V 0 2.5 V 2.53 V +58.8 mV to
+61.2 mV
2.47 V
0 1.5 V 1.53 V +58.8 mV to
+61.2 mV
1.47 V
0 0.5 V 530 mV +58.8 mV to
+61.2 mV
470 mV
3.4 V 0 3.4 V 3.43 V +58.8 mV to
+61.2 mV
3.37 V
0 2.4 V 2.43 V +58.8 mV to
+61.2 mV
2.37 V
-3.4 V 0 -3.4 V -3.37 V +58.8 mV to
+61.2 mV
-3.43 V
0 -2.4 V -2.37 V +58.8 mV to
+61.2 mV
-2.43 V
-1.5 V 0 -2.5 V -2.47 V +58.8 mV to
+61.2 mV
-2.53 V
0 -1.5 V -1.47 V +58.8 mV to
+61.2 mV
-1.53 V
0 -0.5 V -470 mV +58.8 mV to
+61.2 mV
-530 mV
Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)
190 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
