Tektronix MSO70000C/DX Technical Reference

Ch Scale
setting
Termination
setting
Position
setting
(Divs)
Offset
setting
Generat
or
setting
Measurement
mean
Difference of
measurement
means
Accuracy limits
Ch1 140 mV 0 V 0 –1 V –580 mV +823.2 mV to
+856.8 mV
–1.42 V
0 0 V 420 mV +823.2 mV to
+856.8 mV
–420 mV
0 +1 V 1.42 V +823.2 mV to
+856.8 mV
580 mV
Ch1 200 mV 0 V 0 –0.9 V –300 mV +1.176 V to
+1.224 V
–1.50 V
0 0 V 600 mV +1.176 V to
+1.224 V
–600 mV
0 +0.9 V 1.50 V +1.176 V to
+1.224 V
300 mV
Ch1 400 mV 0 V 0 –0.3 V 900 mV +2.352 V to
+2.448 V
–1.50 V
0 0 V 1.20 V +2.352 V to
+2.448 V
–1.20 V
0 +0.3 V 1.50 V +2.352 V to
+2.448 V
–900 mV
Ch2 6.25 mV 0 V 0 0 V 19 mV +37.24 mV to
+38.76 mV
-19 mV
0 +1 V 1.019 V +37.24 mV to
+38.76 mV
981 mV
0 -1 V -981 mV +37.24 mV to
+38.76 mV
-1.019 V
1.5 V 0 2.5 V 2.519 V +37.24 mV to
+38.76 mV
2.481 V
0 1.5 V 1.519 V +37.24 mV to
+38.76 mV
1.481 V
0 0.5 V 519 mV +37.24 mV to
+38.76 mV
481 mV
3.4 V 0 3.4 V 3.419 V +37.24 mV to
+38.76 mV
3.381 V
0 2.4 V 2.419 V +37.24 mV to
+38.76 mV
2.381 V
Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)
194 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
