Tektronix MSO70000C/DX Technical Reference

Ch Scale
setting
Termination
setting
Position
setting
(Divs)
Offset
setting
Generat
or
setting
Measurement
mean
Difference of
measurement
means
Accuracy limits
1.5 V 0 2.5 V 2.65 V +294 mV to
+306 mV
2.35 V
0 1.5 V 1.65 V +294 mV to
+306 mV
1.35 V
0 0.5 V 650 mV +294 mV to
+306 mV
350 mV
3.4 V 0 3.4 V 3.55 V +294 mV to
+306 mV
3.25 V
0 2.4 V 2.55 V +294 mV to
+306 mV
2.25 V
-3.4 V 0 -3.4 V -3.25 V +294 mV to
+306 mV
-3.55 V
0 -2.4 V -2.25 V +294 mV to
+306 mV
-2.55 V
-1.5 V 0 -2.5 V -2.35 V +294 mV to
+306 mV
-2.65 V
0 -1.5 V -1.35 V +294 mV to
+306 mV
-1.65 V
0 -0.5 V -350 mV +294 mV to
+306 mV
-650 mV
Ch4 100 mV 0 V 0 0 V 300 mV +588 mV to
+612 mV
-300 mV
0 +1 V 1.3 V +588 mV to
+612 mV
700 mV
0 -1 V -700 mV +588 mV to
+612 mV
-1.3 V
1.5 V 0 2.5 V 2.8 V +588 mV to
+612 mV
2.2 V
0 1.5 V 1.8 V +588 mV to
+612 mV
1.2 V
0 0.5 V 800 mV +588 mV to
+612 mV
200 mV
3.4 V 0 3.4 V 3.70 V +588 mV to
+612 mV
3.10 V
0 2.4 V 2.70 V +588 mV to
+612 mV
2.10 V
Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 207
