Tektronix MSO70000C/DX Technical Reference

Channel Scale
setting
Position
setting
(Divs)
Offset
setting
Generator
setting
Measurement
mean
Difference of
measurement
means
Accuracy limits
100 mV 0 0 V +380 mV +744.80 mV to +775.20 mV
-380 mV
-5 +2.0 V +2.88 V +744.80 mV to +775.20 mV
+2.12 V
5 -2.0 V -2.12 V +744.80 mV to +775.20 mV
-2.88 V
200 mV 0 0 V +760 mV +1.49 V to +1.55 V
-760 mV
-5 +1.25 V +3.01 V +1.49 V to +1.55 V
+1.49 V
5 -1.25 V -1.49 V +1.49 V to +1.55 V
-3.01 V
Ch3 500 mV 0 0 V +1.90 V +3.724 V to +3.876 V
-1.90 V
-5 0 V +4.40 V +3.724 V to +3.876 V
+0.60 V
5 0 V -0.60 V +3.724 V to +3.876 V
–4.40 V
Ch4 10 mV 0 0 V +38.0 mV +74.48 mV to +77.52 mV
-38.0 mV
-5 +0.45 V +538 mV +74.48 mV to +77.52 mV
+462 mV
5 -0.45 V -462 mV +74.48 mV to +77.52 mV
-538 mV
20 mV 0 0 V +76.0 mV +148.960 mV to +155.040 mV
-76.0 mV
-5 +0.4 V +576.0 mV +148.960 mV to +155.040 mV
+424.0 mV
5 -0.4 V -424.0 mV +148.960 mV to +155.040 mV
-576.0 mV
50 mV 0 0 V +190 mV +372.40 mV to +387.60 mV
-190 mV
-5 +0.25 V +690 mV +372.40 mV to +387.60 mV
+310 mV
5 -0.25 V -310 mV +372.40 mV to +387.60 mV
-690 mV
Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)
216 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
