Select Analog Only (for tests with BWE on, select Digital Filters
(DSP) Enabled).
■
Set the vertical scale, generator frequency, record length, and sample
rate as indicated in the following table for the instrument under test.
Table 17: Delta time measurement settings, ≥4 GHz models
Instrument Volts/div Sine wave
generator
frequency
Record
length
Sample rate
(IT mode)
Burst
width
Delta time rms
accuracy limit
Delta time pk-pk
accuracy limit
BWE off
MSO/DPO72004C 10 mV 9.94 GHz 10000 500 GS/s 10 ns 1.280 ps 12.80 ps
50 mV 9.94 GHz 10000 500 GS/s 10 ns 1.172 ps 11.72 ps
100 mV 9.94 GHz 10000 500 GS/s 10 ns 1.186 ps 11.86 ps
MSO/DPO71604C 10 mV 9.94 GHz 10000 500 GS/s 10 ns 1.280 ps 12.80 ps
50 mV 9.94 GHz 10000 500 GS/s 10 ns 1.172 ps 11.72 ps
100 mV 9.94 GHz 10000 500 GS/s 10 ns 1.186 ps 11.86 ps
MSO/DPO71254C 10 mV 7.76 GHz 10000 500 GS/s 10 ns 1.304 ps 13.04 ps
50 mV 7.76 GHz 10000 500 GS/s 10 ns 1.201 ps 12.01 ps
100 mV 7.76 GHz 10000 500 GS/s 10 ns 1.205 ps 12.05 ps
MSO/DPO70804C 10 mV 4.97 GHz 10000 500 GS/s 10 ns 1.462 ps 14.62 ps
50 mV 4.97 GHz 10000 500 GS/s 10 ns 1.295 ps 12.95 ps
100 mV 4.97 GHz 10000 500 GS/s 10 ns 1.336 ps 13.36 ps
MSO/DPO70604C 10 mV 3.73 GHz 10000 500 GS/s 10 ns 1.625 ps 16.25 ps
50 mV 3.73 GHz 10000 500 GS/s 10 ns 1.427 ps 14.27 ps
100 mV 3.73 GHz 10000 500 GS/s 10 ns 1.463 ps 14.63 ps
MSO/DPO70404C 10 mV 2.48 GHz 10000 500 GS/s 10 ns 2.022 ps 20.22 ps
50 mV 2.48 GHz 10000 500 GS/s 10 ns 1.762 ps 17.62 ps
100 mV 2.48 GHz 10000 500 GS/s 10 ns 1.821 ps 18.21 ps
BWE on
MSO/
DPO73304DX,
33 GHz
6.25 mV 19.49 GHz 10000 500 GS/s 10 ns 0.803 ps 8.03 ps
50 mV 19.49 GHz 10000 500 GS/s 10 ns 0.564 ps 5.64 ps
100 mV 19.49 GHz 10000 500 GS/s 10 ns 0.555 ps 5.55 ps
MSO/
DPO72504DX,
25 GHz
6.25 mV 15.53 GHz 10000 500 GS/s 10 ns 0.881 ps 8.81 ps
50 mV 15.53 GHz 10000 500 GS/s 10 ns 0.639 ps 6.39 ps
100 mV 15.53 GHz 10000 500 GS/s 10 ns 0.639 ps 6.39 ps
MSO/
DPO72304DX,
23 GHz
6.25 mV 14.28 GHz 10000 500 GS/s 10 ns 0.889 ps 8.89 ps
50 mV 14.28 GHz 10000 500 GS/s 10 ns 0.666 ps 6.66 ps
100 mV 14.28 GHz 10000 500 GS/s 10 ns 0.677 ps 6.77 ps
