DC Balance
Performance checks Vertical scale Low limit Test result High limit
Channel 2 DC Balance,
1 MΩ, 250 MHz BW
20 mV/div -4 mV 4 mV
Channel 2 DC Balance,
50 Ω, Full BW
20 mV/div -2 mV 2 mV
Channel 2 DC Balance,
1 MΩ, Full BW
20 mV/div -4 mV 4 mV
Channel 3 DC Balance,
50 Ω, 20 MHz BW
1 mV/div -0.2 mV 0.2 mV
2 mV/div -0.2 mV 0.2 mV
5 mV/div -0.5 mV 0.5 mV
10 mV/div -1 mV 1 mV
20 mV/div -2 mV 2 mV
50 mV/div -5 mV/div 5 mV/div
100 mV/div -10 mV 10 mV
200 mV/div -20 mV/div 20 mV/div
500 mV/div -50 mV/div 50 mV/div
1 V/div -100 mV 100 mV
Channel 3 DC Balance,
1 MΩ, 20 MHz BW
1 mV/div -0.2 mV 0.2 mV
2 mV/div -0.4 mV 0.4 mV
5 mV/div -1 mV/div 1 mV/div
10 mV/div -2 mV 2 mV
20 mV/div -4 mV/div 4 mV/div
100 mV/div -20 mV 20 mV
500 mV/div -100 mV/div 100 mV/div
1 V/div -200 mV 200 mV
10 V/div -2 V 2 V
Channel 3 DC Balance,
50 Ω, 250 MHz BW
20 mV/div -2 mV 2 mV
Channel 3 DC Balance,
1 MΩ, 250 MHz BW
20 mV/div -4 mV 4 mV
Channel 3 DC Balance,
50 Ω, Full BW
20 mV/div -2 mV 2 mV
Channel 3 DC Balance,
1 MΩ, Full BW
20 mV/div -4 mV 4 mV
Performance verification (MSO/DPO5000/B series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 289
