Tektronix MSO70000C/DX Technical Reference

DC Gain Accuracy
Performance checks Bandwidth Vertical scale Low limit Test result High limit
Channel 2 DC Gain
Accuracy, 0 V offset,
0 V vertical position,
1 MΩ
20 MHz 2 mV/div -1.5% 1.5%
5 mV/div -1.5% 1.5%
10 mV/div -1.5% 1.5%
20 mV/div -1.5% 1.5%
50 mV/div -1.5% 1.5%
100 mV/div -1.5% 1.5%
200 mV/div -1.5% 1.5%
500 mV/div -1.5% 1.5%
1 V/div -1.5% 1.5%
250 MHz 20 mV/div -1.5% 1.5%
FULL 20 mV/div -1.5% 1.5%
Channel 3 DC Gain
Accuracy, 0 V offset,
0 V vertical position,
50 Ω
20 MHz 2 mV/div -1.5% 1.5%
5 mV/div -1.5% 1.5%
10 mV/div -1.5% 1.5%
20 mV/div -1.5% 1.5%
50 mV/div -1.5% 1.5%
100 mV/div -1.5% 1.5%
200 mV/div -1.5% 1.5%
500 mV/div -1.5% 1.5%
1 V/div -1.5% 1.5%
250 MHz 20 mV/div -1.5% 1.5%
FULL 20 mV/div -1.5% 1.5%
Channel 3 DC Gain
Accuracy, 0 V offset,
0 V vertical position,
1 MΩ
20 MHz 2 mV/div -1.5% 1.5%
5 mV/div -1.5% 1.5%
10 mV/div -1.5% 1.5%
20 mV/div -1.5% 1.5%
50 mV/div -1.5% 1.5%
100 mV/div -1.5% 1.5%
200 mV/div -1.5% 1.5%
500 mV/div -1.5% 1.5%
1 V/div -1.5% 1.5%
250 MHz 20 mV/div -1.5% 1.5%
FULL 20 mV/div -1.5% 1.5%
Performance verification (MSO/DPO5000/B series)
292 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
