Tektronix MSO70000C/DX

Analog Bandwidth
Performance checks
Bandwidth at
Channel
Impedance Vertical scale Horizontal
scale
V
in-pp
V
bw-pp
Limit Test result
Gain = V
bw-pp
/
V
in-pp
Channel 2 50 Ω 1 mV/div 5 ns/div
(175 MHz)
≥ 0.707
2 mV/div 2.5 ns/div
(350 MHz)
≥ 0.707
5 mV/div
MSO/DPO5204/
B
MSO/DPO5104/
BMSO/
DPO5054/
BMSO/
DPO5034/B
1 ns/div
(1.5 GHz)
(Full BW)
≥ 0.707
10 mV/div 1 ns/div
(Full BW)
≥ 0.707
50 mV/div 1 ns/div
(Full BW)
≥ 0.707
100 mV/div 1 ns/div
(Full BW)
≥ 0.707
1 V/div 1 ns/div
(Full BW)
≥ 0.707
MSO5204/B, DPO5204/B, MSO5104/B, DPO5104/B Only
Channel 2 1 MΩ 1 mV/div 5 ns/div
(175 MHz)
≥ 0.707
2 mV/div 2.5 ns/div
(350 MHz)
≥ 0.707
5 mV/div 1 ns/div
(Full BW)
≥ 0.707
10 mV/div 1 ns/div
(Full BW)
≥ 0.707
50 mV/div 1 ns/div
(Full BW)
≥ 0.707
100 mV/div 1 ns/div
(Full BW)
≥ 0.707
1 V/div 1 ns/div
(Full BW)
≥ 0.707
All Models
Performance verification (MSO/DPO5000/B series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 297
