Tektronix MSO70000C/DX Technical Reference

Random Noise, Sample Acquisition Mode
Performance checks Vertical sensitivity = 100 mV/div
1 MΩ 50 Ω
Bandwidth Test result (mV) High limit (mV) Test result (mV) High limit (mV)
Channel 3 Full 8.13 8.13
250 MHz limit 6.10 6.10
20 MHz limit 4.10 4.10
Channel 4 Full 8.13 8.13
250 MHz limit 6.10 6.10
20 MHz limit 4.10 4.10
Random Noise, Sample Acquisition Mode
Performance checks Vertical sensitivity = 100 mV/div
1 MΩ 50 Ω
Bandwidth Test result (mV) High limit (mV) Test result (mV) High limit (mV)
MSO5204B, DPO5204B
Channel 1 Full 6.1 5.0
250 MHz limit 3.7 3.8
20 MHz limit 3.1 4.0
Channel 2 Full 6.1 5.0
250 MHz limit 3.7 3.8
20 MHz limit 3.1 4.0
Channel 3 Full 6.1 5.0
250 MHz limit 3.7 3.8
20 MHz limit 3.1 4.0
Channel 4 Full 6.1 5.0
250 MHz limit 3.7 3.8
20 MHz limit 3.1 4.0
MSO5104B, DPO5104B
Channel 1 Full 4.5 4.5
250 MHz limit 3.7 3.8
20 MHz limit 3.0 4.0
Channel 2 Full 4.5 4.5
250 MHz limit 3.7 3.8
20 MHz limit 3.0 4.0
Channel 3 Full 4.5 4.5
250 MHz limit 3.7 3.8
20 MHz limit 3.0 4.0
Performance verification (MSO/DPO5000/B series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 301
