Tektronix MSO70000C/DX Technical Reference

Delta Time Measurement Accuracy
Sample rate = 2.5 GS/s, 4 ns/Div, Source freq = 240 MHz
MSO/DPO V/Div Source V
pp
Test result High limit
1 mV 8 mV NA
5 mV 40 mV 234 ps
100 mV 800 mV 233 ps
500 mV 4 V 233 ps
1 V 4 V 237 ps
Sample rate = 2.5 GS/s, 40 ns/Div, Source freq = 24 MHz
1 mV 8 mV 735 ps
5 mV 40 mV 422 ps
100 mV 800 mV 257 ps
500 mV 4 V 254 ps
1 V 4 V 581 ps
Sample rate = 2.5 GS/s, 400 ns/Div, Source freq = 2.4 MHz
1 mV 8 mV 6.99 ns
5 mV 40 mV 3.54 ns
100 mV 800 mV 2.72 ns
500 mV 4 V 2.69 ns
1 V 4 V 5.34 ns
Sample rate = 250 MS/s, 4 μs/Div, Source freq = 240 kHz
1 mV 8 mV 69.9 ns
5 mV 40 mV 35.4 ns
100 mV 800 mV 27.2 ns
500 mV 4 V 26.9 ns
1 V 4 V 53.4 ns
Sample rate = 25 MS/s, 40 μs/Div, Source freq = 24 kHz
1 mV 8 mV 699 ns
5 mV 40 mV 354 ns
100 mV 800 mV 272 ns
500 mV 4 V 269 ns
1 V 4 V 534 ns
Sample rate = 2.5 MS/s, 400 μs/Div, Source freq = 2.4 kHz
1 mV 8 mV 6.99 μs
5 mV 40 mV 3.54 μs
100 mV 800 mV 2.72 μs
500 mV 4 V 2.69 μs
1 V 4 V 5.34 μs
MSO/DPO5054/B and MSO/DPO5034/B Channel 4
Performance verification (MSO/DPO5000/B series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 313
