Tektronix MSO70000C/DX Technical Reference

Digital Threshold Accuracy, MSO5000/B series only
Performance checks:
Digital channel Threshold V
s–
V
s+
Low limit Test result High limit
D0 0 V -0.1 V 0.1 V
4 V 3.78 V 4.22 V
D1 0 V - 0.1 V 0.1 V
4 V 3.78 V 4.22 V
D2 0 V -0.1 V 0.1 V
4 V 3.78 V 4.22 V
D3 0 V -0.1 V 0.1 V
4 V 3.78 V 4.22 V
D4 0 V -0.1 V 0.1 V
4 V 3.78 V 4.22 V
D5 0 V -0.1 V 0.1 V
4 V 3.78 V 4.22 V
D6 0 V -0.1 V 0.1 V
4 V 3.78 V 4.22 V
D7 0 V -0.1 V 0.1 V
4 V 3.78 V 4.22 V
D8 0 V -0.1 V 0.1 V
4 V 3.78 V 4.22 V
D9 0 V -0.1 V 0.1 V
4 V 3.78 V 4.22 V
D10 0 V -0.1 V 0.1 V
4 V 3.78 V 4.22 V
D11 0 V -0.1 V 0.1 V
4 V 3.78 V 4.22 V
D12 0 V -0.1 V 0.1 V
4 V 3.78 V 4.22 V
D13 0 V -0.1 V 0.1 V
4 V 3.78 V 4.22 V
D14 0 V -0.1 V 0.1 V
4 V 3.78 V 4.22 V
D15 0 V -0.1 V 0.1 V
4 V 3.78 V 4.22 V
Performance verification (MSO/DPO5000/B series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 315
