Tektronix MSO70000C/DX

MSO/DPO72004C
MSO/DPO71604C
MSO/DPO71254C
where applicable
20 GHz 19 GHz 18 GHz 17 GHz 16 GHz 15 GHz
2.5 V 17.77 mV 17.87 mV 14.82 mV 12.26 mV 9.96 mV 10.51 mV
3.0 V 25.05 mV 20.20 mV 16.88 mV 14.24 mV 12.17 mV 12.32 mV
4.0 V 33.34 mV 24.86 mV 21.17 mV 18.26 mV 17.07 mV 15.98 mV
4.5 V 35.86 mV 27.20 mV 23.29 mV 20.25 mV 18.6 mV 17.80 mV
5.0 V 38.40 mV 29.53 mV 25.41 mV 22.23 mV 20.29 mV 19.61 mV
MSO/DPO72004C
MSO/DPO71604C
MSO/DPO71254C
where applicable
14 GHz 13 GHz 12.5 GHz 12 GHz 11 GHz 10 GHz
Gain Setting, full scale
100 mV 0.58 mV 0.58 mV 0.55 mV 0.53 mV 0.51 mV 0.49 mV
150 mV 0.77 mV 0.73 mV 0.72 mV 0.71 mV 0.68 mV 0.65 mV
200 mV 0.87 mV 0.84 mV 0.82 mV 0.81 mV 0.78 mV 0.75 mV
300 mV 1.28 mV 1.26 mV 1.28 mV 1.20 mV 1.16 mV 1.10 mV
400 mV 1.63 mV 1.59 mV 1.67 mV 1.49 mV 1.43 mV 1.39 mV
500 mV 1.92 mV 1.85 mV 1.80 mV 1.78 mV 1.72 mV 1.65 mV
600 mV 2.35 mV 2.27 mV 2.42 mV 2.18 mV 2.12 mV 1.99 mV
700 mV 2.79 mV 2.69 mV 2.94 mV 2.58 mV 2.51 mV 2.34 mV
800 mV 3.23 mV 3.10 mV 3.40 mV 2.98 mV 2.90 mV 2.78 mV
900 mV 3.51 mV 3.39 mV 3.63 mV 3.27 mV 3.14 mV 3.02 mV
1.0 V 4.26 mV 4.22 mV 4.09 mV 4.05 mV 3.94 mV 3.73 mV
2.0 V 8.23 mV 7.96 mV 8.39 mV 7.47 mV 7.16 mV 6.93 mV
2.5 V 9.95 mV 9.62 mV 9.57 mV 9.03 mV 8.68 mV 8.35 mV
3.0 V 11.68 mV 11.27 mV 12.35 mV 10.58 mV 10.19 mV 9.76 mV
4.0 V 15.19 mV 15.34 mV 17.26 mV 14.79 mV 14.29 mV 13.60 mV
4.5 V 16.92 mV 17.09 mV 18.49 mV 16.47 mV 15.93 mV 15.12 mV
5.0 V 18.66 mV 18.83 mV 19.60 mV 18.15 mV 17.56 mV 16.65 mV
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series) Vertical system analog channels
(cont.)
30 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
