Tektronix MSO70000C/DX - Page 51

Noise, typical, <4 GHz models
DPO7354C Enhanced
bandwidth
40 GS/s
Step gain 3.5 GHz 3.0 GHz 2.5 GHz 2.0 GHz 1.0 GHz 0.5 GHz
500 mV/div 23.5 mV 20.2 mV 18.9 mV 16.5 mV 12.2 mV 9.7 mV
200 mV/div 10.9 mV 9.2 mV 8.1 mV 7.05 mV 5.3 mV 4.1 mV
100 mV/div 6.6 mV 5.4 mV 4.9 mV 4.2 mV 3.05 mV 2.35 mV
50 mV/div 2.35 mV 2.1 mV 1.9 mV 1.7 mV 1.3 mV 1.0 mV
20 mV/div 1.03 mV 0.89 mV 0.811 mV 0.72 mV 0.53 mV 0.43 mV
10 mV/div 0.61 mV 0.55 mV 0.47 mV 0.42 mV 0.3 mV 0.23 mV
5 mV/div 0.41 mV 0.415 mV 0.41 mV 0.4 mV 0.21 mV 0.16 mV
2 mV/div 0.19 mV 0.19 mV 0.19 mV 0.19 mV 0.185 mV 0.185 mV
1 mV/div 0.12 mV 0.12 mV 0.12 mV 0.12 mV 0.12 mV 0.12 mV
20 GS/s
Step gain 3.5 GHz 3.0 GHz 2.5 GHz 2.0 GHz 1.0 GHz 0.5 GHz
500 mV/div 24.3 mV 21.6 mV 19.1 mV 16.7 mV 12.4 mV 9.9 mV
200 mV/div 11.1 mV 9.3 mV 8.4 mV 7.1 mV 5.35 mV 4.2 mV
100 mV/div 6.65 mV 5.5 mV 4.95 mV 4.25 mV 3.1 mV 2.4 mV
50 mV/div 2.45 mV 2.2 mV 1.95 mV 1.8 mV 1.35 mV 1.1 mV
20 mV/div 1.055 mV 0.93 mV 0.83 mV 0.75 mV 0.55 mV 0.435 mV
10 mV/div 0.625 mV 0.55 mV 0.475 mV 0.425 mV 0.31 mV 0.24 mV
5 mV/div 0.415 mV 0.415 mV 0.415 mV 0.415 mV 0.215 mV 0.16 mV
2 mV/div 0.19 mV 0.19 mV 0.19 mV 0.19 mV 0.185 mV 0.185 mV
1 mV/div 0.12 mV 0.12 mV 0.12 mV 0.12 mV 0.12 mV 0.12 mV
10 GS/s
Step gain 3.5 GHz 3.0 GHz 2.5 GHz 2.0 GHz 1.0 GHz 0.5 GHz
500 mV/div 25.8 mV 22.2 mV 20.0 mV 17.7 mV 13.2 mV 10.4 mV
200 mV/div 11.7 mV 9.9 mV 8.7 mV 7.5 mV 5.5 mV 4.3 mV
100 mV/div 6.9 mV 5.6 mV 5.0 mV 4.3 mV 3.2 mV 2.4 mV
50 mV/div 2.6 mV 2.3 mV 2.05 mV 1.85 mV 1.4 mV 1.15 mV
20 mV/div 1.11 mV 0.99 mV 0.87 mV 0.77 mV 0.58 mV 0.45 mV
10 mV/div 0.65 mV 0.55 mV 0.49 mV 0.43 mV 0.32 mV 0.25 mV
5 mV/div 0.415 mV 0.42 mV 0.42 mV 0.42 mV 0.22 mV 0.16 mV
2 mV/div 0.19 mV 0.19 mV 0.19 mV 0.19 mV 0.185 mV 0.185 mV
1 mV/div 0.12 mV 0.12 mV 0.12 mV 0.12 mV 0.12 mV 0.12 mV
DPO7354C Without enhanced
bandwidth
40 GS/s
Step gain 2.5 GHz 0.5 GHz 0.25 GHz 0.02 GHz
500 mV/div 23.5 mV 16.3 mV 14.5 mV 14.0 mV
200 mV/div 10.7 mV 6.9 mV 6.1 mV 5.8 mV
Vertical system analog channels (cont.) Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C
series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 39
