Tektronix MSO70000C/DX Technical Reference

Edge trigger sensitivity not DC
coupled, typical
All sources, positive or negative edge, for vertical scale settings ≥10 mV/div and ≤1 V/div
≥4 GHz models
Trigger Coupling Sensitivity
NOISE REJ 15%FS from DC to 50 MHz
35%FS at 3 GHz
50%FS at 5 GHz
AC Same as DC-coupled limits for frequencies >
100 Hz, attenuates signals <100 Hz
HF REJ Same as DC-coupled limits for frequencies <
20 kHz, attenuates signals > 20 kHz
LF REJ Same as DC-coupled limits for frequencies >
200 kHz, attenuates signals < 200 kHz
<4 GHz models
Trigger coupling Sensitivity
NOISE REJ 3 times the DC-coupled limits
AC Same as DC-coupled limits for frequencies >
100 Hz, attenuates signals <100 Hz
HF REJ Same as DC-coupled limits for frequencies <
20 kHz, attenuates signals > 20 kHz
LF REJ Same as DC-coupled limits for frequencies >
200 kHz, attenuates signals < 200 kHz
Trigger level or threshold range
>20 GHz models
Trigger Source Range
Any channel ±100% FS from center of screen
Auxiliary input ±4.0 V
Line 0 V, Not settable
≥4 GHz, ≤20 GHz models
Trigger Source Range
Any channel ±120% FS from center of screen
Auxiliary input ±4.0 V
Line 0 V, Not settable
<4 GHz models
Trigger Source Range
Any channel ±12 divisions from center of screen
Auxiliary input ±5 V
Line Not settable
Trigger specifications (cont.) Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 59
