Tektronix MSO70000C/DX

High speed serial trigger, serial
word recognizer position accuracy
≥4 GHz models ± 200 ps
<4 GHz models
Acquisition mode
Sample, Average ± (1 waveform interval + 200 ps)
Peak Detect, Envelope ± (2 waveform intervals + 200 ps)
Serial trigger decoding types
≥4 GHz models
≤ 1.25 GB: NRZ
≤ 1.25 GB: 1.25 GB to 6.25 GB: 8B10B
<4 GHz models NRZ
Serial trigger baud rate limits
≥4 GHz models
NRZ Up to 1.25 GBd
8B10B, typical NRZ 8B10B encoded data at the following bit
rates:
1.25 GBd,
1.50 GBd,
1.57 GBd,
1.62 GBd,
1.65 GBd,
2.00 GBd,
2.50 GBd,
2.7 GBd,
3.00 GBd,
3.125 GBd,
3.2 GBd,
4.25 GBd,
4.80 GBd,
5.00 GBd,
5.4 GBd,
6.00 GBd,
6.25 GBd
Serial trigger baud rate limits,
<4 GHz models
Up to 1.25 GBd (Option PTM adds protocol trigger to DPO7000C Series)
Error detection jitter tolerance ≤ 0.4 UI of total jitter on the signal.
Clock recovery frequency range
≥4 GHz models, typical 1.5 MBaud to 3.125 GBaud. Above 1250 MHz, the clock is only available internally as a trigger
source. Below 1250 MHz, the clock is also available at the recovered clock output along with
regenerated data.
<4 GHz models 1.5 MBaud to 1.25 GBaud.
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series) Serial trigger specifications (cont.)
66 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
