Random noise, sample
acquisition mode
Instrument Bandwidth limit RMS noise
1 MΩ 50 Ω
MSO5204,
DPO5204
Full Bandwidth ≤(180 μV + 8.0% of Volts/div
setting)
≤(150 μV + 6.0% of Volts/div
setting)
250 MHz bandwidth ≤(120 μV + 5.0% of Volts/div
setting)
≤(75 μV + 4.0% of Volts/div
setting)
20 MHz bandwidth ≤(120 μV + 5.0% of Volts/div
setting)
≤(75 μV + 4.0% of Volts/div
setting)
Instrument Bandwidth limit RMS noise
1 MΩ 50 Ω
MSO5104,
DPO5104
Full Bandwidth ≤(150 μV + 8.0% of Volts/div
setting)
≤(75 μV + 6.0% of Volts/div
setting)
250 MHz bandwidth ≤(100 μV + 5.0% of Volts/div
setting)
≤(50 μV + 4.0% of Volts/div
setting)
20 MHz bandwidth ≤(100 μV + 5.0% of Volts/div
setting)
≤(50 μV = 4.0% of Volts/div
setting)
Instrument Bandwidth limit RMS noise
1 MΩ 50 Ω
MSO5054,
DPO5054
Full Bandwidth ≤(130 μV + 8.0% of Volts/div
setting)
≤(130 μV + 8.0% of Volts/div
setting)
250 MHz bandwidth ≤(100 μV + 6.0% of Volts/div
setting)
≤(100 μV + 6.0% of Volts/div
setting)
20 MHz bandwidth ≤(100 μV + 4.0% of Volts/div
setting)
≤(100 μV + 4.0% of Volts/div
setting)
Instrument Bandwidth limit RMS noise
1 MΩ 50 Ω
MSO5034,
DPO5034
Full Bandwidth ≤(130 μV + 8.0% of Volts/div
setting)
≤(130 μV + 8.0% of Volts/div
setting)
250 MHz bandwidth ≤(100 μV + 6.0% of Volts/div
setting)
≤(100 μV + 6.0% of Volts/div
setting)
20 MHz bandwidth ≤(100 μV + 4.0% of Volts/div
setting)
≤(100 μV + 4.0% of Volts/div
setting)
MSO/DPO5204B 50 Ω termination 1 MΩ termination
Vertical Setting Full BW 250 MHz
BW
20 MHz
BW
Full BW 250 MHz
BW
20 MHz
BW
1 mV/div 0.09 0.07 0.20 0.11
2 mV/div 0.20 0.12 0.10 0.45 0.21 0.13
5 mV/div 0.40 0.21 0.20 0.70 0.28 0.24
Analog channel input and vertical specification (cont.) Specifications (MSO/DPO5000/B Series)
