Tektronix MSO70000C/DX Service Manual

Replaceable Parts (DPO7000 Series)
Table 5-2: Repl
aceable parts – Front panel and display (DPO7000 Series)
Fig. & index
number
Tektronix part
number
Serial no.
effective
Serial no.
discont’d Qty Name & descrip
tion
5-2
FRONT PANEL AN
D DISPLAY
-1 174-5165-00 1
CABLE ASSY; POWER SWITCH
-2 211-1221-00 2
SCREW; M2.0 6-MM LONG PHILLIPS FLATHEAD ZINC-PLATED
-3 671-6107-00 1
CIRCUIT BOA
RD ASSY; USB
-4 211-1050-00 4
SCREW, MACHINE; 6-32 X 0.312 L, PNH, STL CAD PLT, T15
-5
174-5164-0
0
1
CA ASSY; USB 2.0
-6 065-0756-01 1
MODULAR AS
SY, FRONT PANEL,TERMINATOR
-7
407-5140-00 1
BRACKET; TRIM, FRONT PANEL, SHEET METAL, SAFETY CONTROLLED
-8 065-0760-
01
1
CIRCUIT BD ASSY; FRONT PANEL; TERMINATOR
-9 671-6062-00 1
CIRCUIT B
D ASSY; FRONT PANEL ENCODER; TERMINATOR
-10 366-0859-01 1
ASSEMBLY, KNOB; 470 DIAMETER, SOFT TOUCH
-11 366-0860
-01
1
ASSEMBLY, KNOB; .685 DIAMETER, SOFT TOUCH
-12 366-0861-01 1
ASSEMBL
Y, KNOB; .925 DIAMETER, SOFT TOUCH
-13 174-5162-00 1
CABLE ASSY; DISPLAY ADAPTER TO FRONT PANEL BOARD
-14 211-07
47-00
8
SCREW, MACHINE; 6-32 X 0.188, PNH, STL, CDPL, T-15 TORX DR
-15 211-0721-00 4
SCREW,
MACHINE; 6-32 X 0.375, PNH, STL, CDPL, T-15 TORX DR
-16 065-0742-00 1
MODULE ASSY; SERVICE REPLACEMENT, TOUCH PANEL W/ PACKAGING
-17 065-07
66-01
1
MODULE ASSY; SERVICE REPLACEMENT, LCD, INTERCONNECT DISPLAY
ADAPTER BOARD W/PACKAGING
-18 174-5
160-00
1
CABLE ASSY; DISPLAY ADAPTER TO DISPLAY
-19 065-0746-01 1
POWER
BUTTON ASSEMBLY
MSO70000/C, DSA70000B/C, DPO70000B/C, D PO7000, MSO5000, DPO5000 Series 5–5
