Tektronix PG 508 Technical Manual

TM 11-6625-2980-14
FO-16
Index
No. Qty 1 2 3 4 5 Name & Description
-36 3 BASE,LAMPHOLDER:0.29 OD X 0.19 CASE
-37 3 LAMPHOLDER:WHITE PLASTIC
-38 3 WASHER,FLAT:0.265 ID X 0.375 OD INCH AL
-39 2 LAMP,LED: (DS110 AND DS1250) EPL
-40 1 LAMP,LED: (DS500 )
-41 1 SHIELD,ELEC:REAR SUBPANEL
-42 1 CKT BOARD ASSY:AUXILLARY(A5)
-43 6 • CONTACT,ELEC:0.365L X 0.25 PH BRZ GOLD PL
-44 2 GUIDE,CKT BOARD:
(ATTACHING PARTS FOR EACH)
-45 2 SCREW,MACHINE:2-56 X 0.312 INCH,RDH STL
-46 2 NUT,PLAIN,HEX.:2-56 X 0.188 INCH,BRS
-47 2 WASHER,LOCK:INTL,0.092 ID X 0.175"OD,STL
- - - * - - -
-48 FT PLASTIC CHANNEL:
-49 1 MARKER,IDENT:WARNING
-50 1 PANEL,REAR:
(ATTACHING PARTS)
-51 4 SCR,TPG,THD FOR:6-32 X 0.50 INCH,PNH STL
- - - * - - -
-52 1 CKT BOARD ASSY:MAIN(A4 )
(ATTACHING PARTS)
-53 4 SCREW,MACHINE:6-32 X 0.375 INCH,PNH STL
-54 4 BRACKET,COVER:TOP AND BOTTOM
-55 4 SCR,ASSEM WSHR:4-40 X 0.312 INCH,PNH STL
-56 1 SCREW,MACHINE:6-32 X 0.250 BDGH,NYL,SLOT
-57 1 SCREW,MACHINE:4-40 X 0.25 INCH,PNH STL
-58 1 NUT,PLAIN,EXT W:4-40 X 0.25 INCH,STL
- - - * - - -
- • CKT BOARD ASSY INCLUDES:
-59 1 • MICROCIRCUIT,DI:( U1205)
-60 1 • SWITCH,PUSH:(S785 AND S865)
-61 4 • SPACER,PB SW:0.164 INCH LONG
-62 4 • SOCKET,PLUG IN:MICROCIRCUIT,8 CONTACT
-63 4 • HEAT SINK,ELEC:XSTR,0.72 OD X 0.375"H
-64 8 • INSULATOR,DISC:TO-5 TRANSISTOR
-65 4 • HEAT SINK,ELEC:0.422 H X 1.240 INCH OD
-66 3 • CONNECTOR BODY,:CKT CD MT,3 PRONG
-67 21 • SOCKET,PIN TERM:0.188 INCH LONG
-68 27 • CONTACT,ELEC:0.365L X 0.25 PH BRZ GOLD PL
-69 1 • SOCKET,PLUG-IN:14 CONTACT,LOW CLEARANCE
-70 4 • TERM.,TEST PT:0.40 INCH LONG
-71 3 • LINK,TERM.CONNE:0.086 DIA X 2.375 INCH L
-72 2 • LINK,TERM.CONNE:2 WIRE BLACK
-73 2 • CLAMP,LOOP:NYLON
-74 1 • HEAT SINK,DIODE:FINGER TYPE
(ATTACHING PARTS)
-75 1 • SCREW,MACHINE:4-40 X 0.25 INCH,PNH STL
-76 1 • NUT,PLAIN,EXT W:4-40 X 0.25 INCH,STL
- - - * - - -
-77 1 • MICROCIRCUIT,LI: (U1335)
-78 3 • CONTACT,ELEC:1.37 INCH LONG
-79 1 • CONN BODY,BPL,EL:3 WIRE RED
-80 3 • CONNECTOR,TERM.:0.48" L,22-26AWG WIRE
-81 1 INS,STANDOFF:0.312 OD X 1.0 INCH LONG
(ATTACHING PARTS)
-82 1 SCREW,MACHINE:6-32 X 0.25 INCH,PNH STL
- - - * - - -
1 CKT BOARD ASSY:MAIN W/CAM SW
1 • CONTACT,ELEC:GROUNDING
1 • ACTR ASSY CAM S:RANGE(S590 )
(ATTACHING PARTS)
-83 4 • SCR,ASSEM WSHR:4-40 X 0.312 INCH,PNH STL
- - - * - - -
5-12
