TM 11-6625-2980-14
FO-16
Index
No. Qty 1 2 3 4 5 Name & Description
-1 2 SHIELD,ELEC: SIDE
-2 2 COVER,PLUG-IN:TOP AND BOTTOM
(ATTACHING PARTS)
-3 2 SCREW,MACHINE:6-32 X 0.188 INCH,PNH STL
- - - * - - -
-4 1 KNOB,LATCH:
(ATTACHING PARTS)
-5 1 PIN,KNOB SECRG:0.094 OD X 0.120 INCH LONG
- - - * - - -
-6 3 KNOB:GRAY
- • EACH KNOB INCLUDES:
1 • SETSCREW:5-40 X 0.125 INCH,HEX SOC STL
-7 3 KNOB:GRAY,0.25 ID X 0.706 OD,0.6H
- • EACH KNOB INCLUDES:
2 • SETSCREW:5-40 X 0.125 INCH,HEX SOC STL
-8 1 KNOB:GRAY,O.81 ID X 0.392 OD,0.466 H
1 • SETSCREW:4-40 X 0.125 INCH,HEX SOC STL
-9 1 KNOB:GRAY,0.126 IDX 0.588 OD,0.6H
1 • SETSCREW:5-40 X 0.125 INCH,HEX SOC STL
-10 1 KNOB:0.252 ID X0.706 OD,0.6H
1 • SETSCREW:5-40 X 0.125 INCH,HEX SOC STL
-11 3 KNOB:GRAY,0.127 IDX 0.5 OD,0.531H
- • EACH KNOB INCLUDES:
1 • SETSCREW:5-40 X 0.125 INCH,HEX SOC STL
-12 7 PUSH BUTTON:GRAY
-13 2 CONNECTOR,RCPT, :BNC,FEMALE,W/HARDWARE
-14 2 TERMINAL,LUG:0.391" ID INT TOOTH
-15 1 CONNECTOR,RCPT,:BNC,FEMALE
-16 1 RESISTOR,VAR:(R48)
(ATTACHING PARTS)
-17 1 NUT,PLAIN,HEX.:0.25-32 X 0.312 INCH,BRS
-18 1 WASHER,FLAT:0.25 ID X 0.375 INCH OD,STL
-19 1 RESISTOR,VAR:(R540 AND R655)
(ATTACHING PARTS FOR EACH)
-20 1 NUT,PLAIN,HEX. :0.25-32 X 0.312 INCH,BRS
-21 1 WASHER,FLAT:0.25 ID X 0.375 INCH OD,STL
-22 1 RESISTOR,VAR:(R770A AND B)
(ATTACHING PARTS)
-23 1 NUT,PLAIN,HEX. :0.25-32 X 0.312 INCH,BRS
-24 4 BSHG,MACH.THD:HEX,0.375-32 X 0.438"LONG
(ATTACHING PARTS)
-25 4 NUT,PLAIN,HEX. :0.375-32 X 0.50 INCH,STL
-26 3 WASHER,FLAT:0.375 ID X 0.50 INCH OD,STL
-27 1 WASHER,LOCK:INTL,0.375 ID X 0.50" OD STL
-28 4 CLIP,ELECTRICAL:CAM SHAFT
-29 2 BUSHING,SLEEVE:PRESS MOUNT
-30 7 FRAME,PUSH BTN:PLASTIC
-31 1 PANEL,FRONT:
-32 1 LATCH,RETAINING:PLUG-IN
(ATTACHING PARTS)
-33 1 SCR,TPG,THD FOR:2-32 X 0.312 INCH,PNH STL
- - - * - - -
1 RELEASE,LATCH:
-34 1 SUBPANEL,FRONT:
(ATTACHING PARTS)
-35 4 SCR,TPG,THD FOR:6-20 X0.375"100 DEG,FLH STL
5-11
