Tektronix PG 508 Technical Manual

TM 11-6625-2980-14
Index
No. Qty 1 2 3 4 5 Name & Description
-1 1 COVER,CAL FXTR:W/HANDLE
(ATTACHING PARTS)
-2 2 SCREW,MACHINE:6-32 X 0.188 INCH,PNH STL
1 SCREW,MIACHINE:8-32 X 0.188,TRH,SST
- - - * - - -
- • COVER INCLUDES:
1 • COVER,CAL FXTR:W/O HANDLE
-3 1 • HANDLE,CARRYING:
(ATTACHING PARTS)
-4
-5
-6 2 • RIVET,BLIND:0.125 OD X 0.357 L,DOMED HEAD
2 • WSHR,SHOULDERED:O.143" ID X 0.75" OD,BRS
- - - * - - -
-7 1 EXTENSION SHAFT:13.612 L X 0.048 STL W/PB
(ATTACHING PARTS)
-8 2 SCREW,MACHINE:4-40 X 0.25" 100 DEG,FLH STL
- - - * - - -
-9 1 ADAPTER,SW ACTR:
-10 1 SWITCH,PUSH-PUL:1OA,250VAC
-11 1 BRACKET,ANGLE:CKT CARD SPRT,LEFT
(ATTACHING PARTS)
-12 2 SCREW,MACHINE:6-32 X 0.312 INCH,PNH STL
-13 4 NUT,PLAIN,EXT W:6-32 X 0.312 INCH,STL
-14 2 SCREW,MACHINE:6-32 X 0.312"100 DEG,FLH STL
- - - * - - -
-15 2 SWITCH,THERMO:(S3,S4)
(ATTACHING PARTS FOR EACH)
-16 2 SCREW,MACHINE:4-40 X 0.25 INCH,PNH STL
-17 2 NUT,PLAIN,EXT W:4-40 X 0.25 INCH,STL
- - - * - - -
-18 1 TERMINAL,LUG:0.146 INCH DIA DE,45 DEG BEND
(ATTACHING PARTS)
-19 1 NUT,PLAIN,EXT W:4-40 X 0.25 INCH,STL
- - - * - - -
-20 1 TRANSFORMER: (T1
(ATTACHING PARTS)
-21 4 SCREW,MACHINE:10-32 X 2.250" HEX.HD STL
-22 4 NUT,EXTENDED WA:10-32 X 0.375 INCH,STL
-23 4 INS SLV,ELEC:0.187 ID X 1.50 INCH LONG
4 WASHER,LOCK:INT,0.20 ID X0.376" OD,STL
1 TERMINAL,LUG:SE #10
- - - * - - -
1 TERMINAL,LUG:SE #8
(ATTACHING PARTS)
1 NUT,PLAIN,EXT W:8-32 X 0.344 INCH,STL
- - - * - - -
-24 1 COVER,ELEC XFMR:
-25 1 CKT BOARD ASSY:INTERFACE(A1)
-26 14 CONTACT,ELEC:0.365 L X 0.25 PH BRZ GOLD PL
-27 3 CONNECTOR,RCPT,:28/56 CONTACT
-28 3 KEY,CONN PLZN:
-29 4 CLIP,ELECTRICAL:FOR 0.25 INCH DIA FUSE
-30 1 RETAINER,CAP:
(ATTACHING PARTS)
-31 2 SCR,ASSEM,WSHR:6-32 X 0.312 INCH,PNH STL
-32 2 NUT,PLAIIJ,HEX. :6-32 X 0.25 INCH,BRS
- - - * - - -
A-20
