No. Qty 1 2 3 4 5 Name & Description
-33 1 LINK,TERM. CONN:8,22 AWG,1.5 L
-34 1 LINK,TERM. CONN:8,22 AWG,1.5 L
-35 1 • BRACKET,REIF·F:
(ATTACHING PARTS)
-36 • DELETED
-37 4 • RIVET,BLIND:0.125 DIA GRIP,AL
- - - * - - -
(ATTACHING PARTS FOR CKT BD ASSY)
-38 2 SCREW,MACHINE:6-32 X 0.375 INCH,PNH STL
-39 2 NUT,CHASSIS MTG:
-40 6 NUT,PLAIN,EXT W:6-32 X 0.312 INCH,STL
-41 6 INSULATOR,WSHR:0.812 OD X 0.0025 INCH THK
6 WASHER,FLAT:0.15 ID X 0.375 INCH OD,STL
- - - * - - -
-42 1 HEAT SINK,XSTR:
-43 1 HEAT SINK,XSTR:
-44 1 BRACKET,ANGLE:CKT CARD SPRT,RIGHT
(ATTACHING PARTS)
-45 2 SCREW,MACHINE:6-32 X 0.312 INCH,PNH STL
-46 4 NUT,PLAIN,EXT W:6-32 X 0.312 INCH,STL
-47 2 SCREW,HACHINE:6-32 X 0.312"100 DEG,FLH STL
- - - * - - -
-48 4 LEG,ELEC EQUIP.:PLASTIC
(ATTACHING PARTS FOR EACH)
-49 1 SCREW,MACHINE:8-32 X 1.5 INCH,PNH,STL
-50 1 NUT,PLAIN,EXT W:8-32 X 0.344 INCH,STL
- - - * - - -
-51 1 PANEL,REAR:OPTION 2
(ATTACHING PARTS)
2 NUT,PLAIN,EXT W:6-32 X 0.312 INCH,STL
2 SCREW,MACHINE:6-32 X 0.375 INCH,PNH STL
- - - * - - -
-52 1 BSHG,STRAIN RLF:
-53 1 CABLE ASSY,PWR:
-54 1 FUSEHOLDER: W/MOUNTING HARDWARE
-55 1 WASHER,NONMETAL:0.5 ID X 0.688 INCH OD,NPRN
-56 3 GUIDE,PL-IN:UPPER
(ATTACHING PARTS FOR EACH)
-57 1 SCREW,MACHINE:2-56 X 0.188" 82 DEG,FLH,STL
- - - * - - -
- - - * - - -
2 HINGE BLOCK,STA:LEFT
2 HINGE BLOCK,STA:RIGHT
1 STAND,ELEC EQPT:
-58 1 FLIPSTAND,CAB.:
1 COVER,PWR SPLY:BOTTOM
1 COVER,PWR SPLY:BOTTOM
1 CAB.BOT,PWR SUP:
(ATTACHING PARTS)
-59 4 SCREW,MACHINE:4-40 X 0.188"100 DEG,FLH STL
- - - * - - -
A-21
