Tektronix PG 508 Technical Manual

TM 11-6625-2980-14
Index
No Qty 1 2 3 4 5 Name & Description
- - • CABINET BOTTOM ASSEMBLY INCLUDES:
-60 1 • CAB.BOT,PWR SUP:
-61 2 • FOOT,CABINET:LEFT FRONT AND RIGHT REAR
-62 2 • SPT PIVOT,FLIP:LEFT FRONT AND RIGHT REAR
(ATTACHING PARTS FOR EACH)
-63 2 • SCREW,IMACHINE:6-32 X 0.75 INCH,FILH STL
-64 2 • NUT,PLAIN,EXT W:6-32 X 0.312 INCH,STL
- - - * - - -
-65 2 • FOOT,CABINET:RIGHT FRONT AND LEFT REAR
-66 2 • SPT PIVOT,FLIP:RIGHT FRONT AND LEFT REAR
(ATTACHING PARTS FOR EACH)
-67 2 • SCREW,MACHINE:6-32 X 0.75 INCH,FILH STL
-68 2 • NUT,PLAIN,EXT W:6-32 X 0.312 INCH,STL
- - - * - - -
-69 3 GUIDE,SLIDE:BLACK
(ATTACHING PARTS)
-70 2 SCREW,MACHINE:4-40 X 0.312"100 DEG,FLH STL
-71 1 SCREW,MACHINE:4-40 X 0.25" 100 DEG,FLH STL
- - - * - - -
1 MARKER,IDENT:MARKED "CAUTION"
2 PLATE,IDENT:WARNING,TRANSISTORS
-72 1 FRAME ASSY,CAB:
-73 3 CONTACT,ELECTRICAL:
(ATTACHING PARTS)
-74 3 EYELET,METALLIC:0.089 OD X 0.125" L,BRASS
- - - * - - -
A-22

Tektronix PG 508 Specifications

General

Brand	Tektronix
Model	PG 508
Category	Pulse Generator
Language	English
