Tektronix RSA306B Installation And Safety Instructions

Introduction
Key features
9 kHz – 6.2 G Hz frequency range
40 MHz real time band wid th
External reference and trigger/sync inputs
USB 3.0 power/control/data interface to PC
Publicly-accessible software application programming interface
(API) for Windows an d Linux operating systems
RSA306B-SMA model provides a SMA connector
RSA306B-SMA with the No-Shell option ships without the plastic
housing, allowing for easier integration into a sys tem
Standard accessories
The instrument ships with the following accessories.
Table 1: Standard accessories
Accessory Tektronix part number
Printed S afety/Installation manual
071-3483-xx
USB 3.0 A-to-Micro-B cable, 1 M
174-6796-xx
USB Flash Drive containing documentation
files and all sup port SW: USB drivers, API
drivers, SignalVu-PC software
063-4543-xx
Optional accessories
Optional accessories that are available for the instrum ent are listed
below.
Table 2: Optional accessories
Accessory Tektronix part number
Soft carrying case RSA300CASE
Hard-sided transit case
RSA300TRANSIT
2 RSA306B and RSA306B-SMA Installation and Safety Instructions
