Installation
4– USB 3.0 connector
Use the USB 3.0 A-to-Micro B cable provided with the signal an a lyzer
to connect the instrument to the USB 3.0 connection on the host PC.
Finger tighten the USB cable thumbscrews to the RSA.
CAUTION. Lock the USB cable to the instrument by c arefully hand
tightening the USB connector thumb screws to maintain a reliable
connection. These screws can e asily be misaligned and can damage the
instrument if the screws are cross-threaded. To limit the ex posure of
cross-threading the screws, you can keep the USB cable attached to th e
RSA, even while moving or transporting the instrument.
5– SMA type RF input connector
This SMA female connector receives the RF signal input, via cable or
antenna. The input signal frequency range is 9 kHz to 6.2 GHz.
12 RSA306B and RSA306B-SMA Installation and Safety Instructions
