Troubleshooting
Diagnostic test error
messages
The following t
ables list the instrument diagnostics error messages, with
recommended actions for each message.
Hardware modu
le (See Table 3-9 on page 3-26.)
Digital interface board (See Table 3-10 on page 3-26.)
ADC board (See Table 3-11 on page 3-27.)
DPSA board (See Table 3-12 on page 3-28.)
RF interface board (See Table 3-13 on page 3-29.)
LO1 module (See Table 3-14 on page 3-30.)
LO2/Refe
rence oscillator (See Table 3-15 on page 3-31.)
Front panel (See Table 3-16 on page 3-34.)
RSA5100B Series Service Manual 3–25
