SPG600 & SPG300 Sync Pulse G enerators Quick Reference Manual

This menu allows you to select a serial digital test signal for the SDI output(s).

Use the up (

Y)ordown(B) arrow button to scroll through the menu. Figure 7

shows the Test signal (SDI) submenu diagram. Use the left (

A)orright(")

arrow button to select a signal.

COLOR BAR

SMPTE Color Bars

Select a signal

Select TEST SIGNAL (SDI) in the Video menu

FLAT FIELD

0% Flat Field

Select a signal

LINEARITY

10 Step

Select a signal

MONITOR

2 Pedestal & Pluge

Select a signal

MULTI BURST

60% Y Multiburst

Select a signal

SWEEP

100% Sweep

Select a signal

SDI

Checkfield

Select a signal

TIMING

2.5 MHz Bowtie

Select a signal

PULSE BAR

2T Pulse & Bar

Select a signal

OTHER

Chroma Freq. Resp.

Select a signal

REC 801

100% Color Bars

Select a signal

Figure 7: Test signal (SDI) submenu diagram
