Reference Notes
These notes are provided to help you utilize the full potential of the TCPA300
and TCPA400 current probe systems.
Degaussing a Probe with an Unpowered Conductor in the Jaws
Under almost all conditions, you can degauss your current probe while a conductor
of an unpow
ered circuit is clamped in the jaws. The advantage of dega ussing
with an unpowered circuit is that any offset from stray DC magnetic fields are
compensated. In an automated environment, degaussing with the conductor in the
probe jaws eliminates the need to manually remove the probe.
NOTE. Be certain that the conductor in the probe jaws is completely unpowered.
Any current flowing through the conductor will cause a residual offset in the
current
probe, and the amplifier may report an inaccurate result.
If the impedance of your circuit is higher than that shown, the degauss procedure
succe
eds because the amplifier is able to saturate the probe core. (See Figure 11
on page 23.) While degauss occurs, the probe induces a voltage in the unpowered
circuit as shown. (See Figure 11 on page 23.) Your circuit must be able to absorb
this induced voltage. With low impedance circuits, several amperes may be
induced in the circuit being measured. This may be of concern when you are
using very small conductors.
Tab
le 3: Unpowered circuit degauss limits
Probe type
Min
imum circuit
resistance Maximum induced voltage
TCP312
10
mW
40
mV at 200 Hz
TCP305
5m
W
40
mV at 200 Hz
TCP303
5
mW
3
0 mV at 200 Hz
TCP404XL
1
mW
1
5 mV at 100 Hz
TCPA300/400 Amplifiers and TCP300/400 Series Current Probes User Manual 21
