Operating Information
TDS 200 Series Digital Oscilloscope Service Manual
2–9
Table 2–1: Factory setup settings (cont.)
Control Setting
Edge trigger level 0.0 V
Edge trigger slope Rising
Edge trigger source Channel 1
Horizontal – main trigger position 50%
Horizontal – time base Main only
Main time base time/div
500 ms/div
Math waveform function CH1 + CH2
Saved setups No change
Saved waveforms No change
Trigger holdoff Minimum (500 ns)
Trigger mode Auto
Trigger type Edge
Vertical bandwidth (all channels) Full
Vertical coupling (all channels) DC
Vertical position (all channels) 0 div
Vertical volts/div. (all channels) 100 mV/div
