Tektronix TDS 500B

Performance Tests
1–24
TDS 500B, TDS 600B & TDS 700A Performance Verification and Specifications
TDS 500B/700A Test Record (Cont.)
Instrument Serial Number: Certificate Number:
Temperature: RH %:
Date of Calibration: Technician:
TDS 500B/700A Performance Test MaximumOutgoingIncomingMinimum
CH2 1 V Vert scale setting,
–5 Div position setting, +10 V offset
+ 17.7575 V __________ __________ + 18.2425 V
CH2 1 V Vert scale setting,
+5 Div position setting, –10 V offset
– 18.2425 V __________ __________ – 17.7575 V
CH3 5 mV Vert scale setting,
or AX1 –5 Div position setting, +1 V offset
+ 1.0355 V __________ __________ + 1.0445 V
CH3 5 mV Vert scale setting,
or AX1 +5 Div position setting, –1 V offset
– 1.0445 V __________ __________ – 1.0355 V
CH3 200 mV Vert scale setting,
or AX1 –5 Div position setting, +10 V offset
+ 11.5195 V __________ __________ + 11.6805 V
CH3 200 mV Vert scale setting,
or AX1 +5 Div position setting, –10 V offset
– 11.6805 V __________ __________ – 11.5195 V
CH3 1 V Vert scale setting,
or AX1 –5 Div position setting, +10 V offset
+ 17.7575 V __________ __________ + 18.2425 V
CH3 1 V Vert scale setting,
or AX1 +5 Div position setting, –10 V offset
– 18.2425 V __________ __________ – 17.7575 V
CH4 5 mV Vert scale setting,
or AX2 –5 Div position setting, +1 V offset
+ 1.0355 V __________ __________ + 1.0445 V
CH4 5 mV Vert scale setting,
or AX2 +5 Div position setting, –1 V offset
– 1.0445 V __________ __________ – 1.0355 V
CH4 200 mV Vert scale setting,
or AX2 –5 Div position setting, +10 V offset
+ 11.5195 V __________ __________ + 11.6805 V
CH4 200 mV Vert scale setting,
or AX2 +5 Div position setting, –10 V offset
– 11.6805 V __________ __________ – 11.5195 V
CH4 1 V Vert scale setting,
or AX2 –5 Div position setting, +10 V offset
+ 17.7575 V __________ __________ + 18.2425 V
CH4 1 V Vert scale setting,
or AX2 +5 Div position setting, –10 V offset
– 18.2425 V __________ __________ – 17.7575 V
Analog Bandwidth
CH1 100 mV 424 mV __________ __________ N/A
CH2 100 mV 424 mV __________ __________ N/A
CH3
or AX1 100 mV
424 mV __________ __________ N/A
CH4
or AX2 100 mV
424 mV __________ __________ N/A
