Tektronix TDS 500B User Manual

Operating Interface Maps
2–8
TDS 684A, TDS 744A, & TDS 784A User Manual
To Operate a Pop-Up Menu
Press to display pop-up menus.
Press it again
to make selection.
Alternatively, press SHIFT first to make
selection in the opposite direction.
A pop-up selection changes the other
main menu titles.
Press here to
remove menus from
screen.

