Appendix D: Factory Initialization Settings
D–6
TDS Family Oscilloscope Programmer Manual
Table D–1: Factory Initialization Settings (Cont.)
Control Changed by Factory Init to
Pulse width trigger polarity
(TDS 5XXA, 6XXA, & 7XXA)
Positive
Pulse width trigger when ...
(TDS 5XXA, 6XXA, & 7XXA)
Within limits
Pulse width upper limit
(TDS 5XXA, 6XXA, & 7XXA)
2.0 ns
RS-232 parameters No change
Saved setups No change
Saved waveforms No change
Stop after R/S button
Vertical bandwidth (all channels) Full
Vertical coupling (all channels) DC
Vertical impedance (termination) (all channels) 1 MW
Vertical offset (all channels) 0 V
Vertical position (all channels) 0 divs.
Vertical volts per division (all channels) 100 mV per division
Zoom dual Off
Zoom dual offset 5 e–3
Zoom graticule Upper
Zoom horizontal (all channels) 1.0X
Zoom horizontal lock All
Zoom horizontal position (all channels) 50% = 0.5 (the middle of the display)
Zoom state Off
Zoom vertical (all channels) 1.0X
Zoom vertical position (all channels) 0 divs.
