TDS Family Oscilloscope Programmer Manual

2–37

Zoom Commands

Zoom commands let you expand and position the waveform display horizontally

and vertically without changing the time base or vertical settings. Table 2–22

lists these commands.

Table 2–22: Zoom Commands

Header Description

ZOOm Reset zoom parameters to defaults

ZOOm:DUAl (TDS 4XXA & 7XXA) Turn dual zoom mode on and off

ZOOm:DUAl:OFFSet (TDS 4XXA & 7XXA) Adjust the requested horizontal offset between

the centers of the main and second zoom

boxes.

ZOOm:GRAticle (TDS 4XXA & 7XXA) Select between the upper and lower graticule

for use by the zoom preview state.

ZOOm:HORizontal:LOCk Horizontal zoom lock

ZOOm:HORizontal:POSition Horizontal zoom position

ZOOm:HORizontal:SCAle Horizontal zoom scale

ZOOm:STATE Turn zoom mode on or off

ZOOm:VERTical:POSition Vertical zoom position

ZOOm:VERTical:SCAle Vertical zoom scale
