Tektronix TDS 700D Technical Reference

Performance Tests
TDS 500D, TDS 600C, TDS 700D & TDS 714L Performance Verification and Specifications
1–19
Table 1–1: Test equipment (cont.)
Item number and
description
PurposeExampleMinimum requirements
15. Meter, Level and Power
Sensor
Frequency range:10 MHz to the
oscilloscope bandwidth. Amplitude
range: 6 mV
p-p
to 2 V
p-p
Rohde & Schwarz URV 35,
with NRV-Z8 power sensor
1,5
Checking Analog Bandwidth
and Trigger Sensitivity
16. Splitter, Power Frequency range: DC to 3 GHz.
Tracking: >2.0%
Tektronix part number
1,5
015-0565-00
Checking Analog Bandwidth
17. Adapter (four required) Male N-to-female BNC Tektronix part number
103-0045-00
Checking Analog Bandwidth
18. Adapter Female N-to-male BNC Tektronix part number
103-0058-00
Checking Analog Bandwidth
19. Adapter 3 SMA male-to-male Tektronix part number
015-1012-00
Checking the delay between
channels
20. Adapter 3 SMA female-to-male BNC Tektronix part number
015-1018-00
Checking the delay between
channels
21. Generator, Video Signal Provides PAL compatible outputs Tektronix TSG 121 Used to Test Video Option 05
Equipped Instruments Only
22. Oscillator, Leveled Sine
wave Generator
60 Hz Sine wave Tegam/Tektronix SG 502
(if available)
1,3
Used to Test Video Option 05
Equipped Instruments Only
23. Pulse Generator Tektronix CFG280
(or Tegam/Tektronix PG 502)
3
Used to Test Video Option 05
Equipped Instruments Only
24. Cable, Coaxial
(two required)
75 W, 36 in, male-to-male BNC
connectors
Tektronix part number
012-1338-00
Used to Test Video Option 05
Equipped Instruments Only
25. Terminator, 75 W
(two required)
Impedance 75 W; connectors: female
BNC input, male BNC output
Tektronix part number
011-0102-01
Used to Test Video Option 05
Equipped Instruments Only
26. Generator, Optical Im-
pulse
850 nm optical impulse Tektronix OIG501 Optical
Impulse Generator
3
Checking Option 3C
27. Generator, Optical Im-
pulse
1300 nm optical impulse Tektronix OIG502 Optical
Impulse Generator
3
Checking Option 4C
28. Cable, Coaxial
(two required)
50 W, 20 in, male-to-male SMA
connectors
Tektronix part number
174-1427-00
Used to Test Delta Time
Measurement Accuracy
29. Adapter SMA “T”, male to 2 SMA female Tektronix part number
015-1016-00
Used to Test Delta Time
Measurement Accuracy
30. Adapter SMA female to BNC male Tektronix part number
015-0572-00
Used to Test Delta Time
Measurement Accuracy
31. Adapter BNC male to female elbow Tektronix part number
103-0031-00
Used to Test Delta Time
Measurement Accuracy
32. Terminator Short circuit, SMA connector Tektronix part number
015-1021-00
Used to Test Delta Time
Measurement Accuracy
33. Attenuator, 2X Ratio: 2X; impedance 50 W; connec-
tors: female BNC input, male BNC
output
Tektronix part number
011-0069-02
Used to Test Delta Time
Measurement Accuracy
