Performance Tests
1–20
TDS 500D, TDS 600C, TDS 700D & TDS 714L Performance Verification and Specifications
Table 1–1: Test equipment (cont.)
Item number and
description
PurposeExampleMinimum requirements
34. Attenuator, Optical 62.5 micron optical attenuator Tektronix OA5022 Optical
Attenuator
3
Checking Option 3C and 4C
35. Cable, Fiber Optic FC-FC fiber cable Tektronix part number
174-2322-00
Checking Option 3C and 4C
36. Optical-to-Electrical
Converter
P6701B (used with Option 3C) or
P6703B (used with Option 4C)
optical-to-electrical converter
Tektronix part number
P6701B or P6703B
Checking Option 3C and 4C
1
You may replace items 9, 10, 11, 14, 15, 16, and 22 with a Wavetek 9100 (with options 100 and 600) for 500 MHz oscillo-
scopes, or a Wavetek 9500 (with option 100) and output head appropriate for the bandwidth of the oscilloscope(s) being
tested. For 3 GHz oscilloscopes use a Wavetek 9530 head.
2
P6139A probe is not appropriate for the TDS694C/794D oscilloscopes.
3
Requires a TM 500 or TM 5000 Series Power Module Mainframe. For Delta Time Measurement Accuracy use a
Wavetek 9500 or a pulse generator with a rise time as shown in Table 1–6 on page 1–58.
4
Warning: The P6243 and P6245 probes that may be used with this oscilloscope provide an extremely low loading
capacitance (<1 pF) to ensure the best possible signal reproduction. These probes should not be used to measure
signals exceeding ±8 V, or errors in signal measurement will be observed. Above 40 V, damage to the probe may result.
To make measurements beyond ±8 V, use either the P6139A probe (good to 500 V), or refer to the catalog for a recom-
mended probe. P6139A is not an appropriate probe for the TDS 694C or TDS 794D oscilloscopes.
5
If available, you may replace items 14, 15, and 16 with the following set of equipment for bandwidths up to 1 GHz:
a Tegam/Tektronix SG503 and SG504 with SG504 leveling head.
