Triggering on Waveforms
TDS 500D, TDS 600B, & TDS 700D User Manual
3–119
2. Use the general purpose knob or the keypad to set the delay time.
If you press Intensified (side), you display an intensified zone on the main
timebase record that shows where the delayed timebase record occurs
relative to the main trigger. For Delayed Runs After Main mode, the start of
the intensified zone corresponds to the start of the delayed timebase record.
The end of the zone corresponds to the end of the delayed record.
NOTE. The intensified zone is not visible when in DPO mode (TDS 500D and
TDS 700D models only); see Incompatible Modes on page 3–66.
To make sure that the Main Trigger menu settings are compatible with Delayed
Triggerable and to select that mode, do the following steps:
1. Press TRIGGER MENU.
2. If Type is set to Logic, press Type (main) to change it to either Edge or
Pulse as fits your application. Logic type is incompatible with Delayed
Triggerable.
3. If Source is set to Auxiliary, press Source (main). Select any source other
than Auxiliary from the side menu according to your application.
To Trigger After Delay
