Command Descriptions
TDS200/1000/2000 Series Oscilloscope Programmer Manual
2−133
SAVe:WAVEform MATH, REFB
saves the math waveform in stored waveform memory location
REFB.
SELect:<wfm> can be used to display a saved reference waveform.
SELect? (Query Only)
Returns the display status of all waveforms.
Vertical
SELect?
Waveform display status
SELect?
2-channel models with CH2, Math and REFB waveforms displayed
would return :SELECT:CH1 0;CH2 1;MATH 1;REFA 0;REFB 1
4-channel models with CH1 through CH4 displayed, Math disabled,
REFA displayed, and REFD displayed would return
:SELECT:CH1 1;CH2 1;CH3 1;CH4 1;MATH 0;REFA 1;REFB
0;REFC 0;REFD 1
Examples
Related Commands
Group
Syntax
Returns
Examples
