Command Descriptions
2−158
TDS200/1000/2000 Series Oscilloscope Programmer Manual
Waveform
WAVFrm?
See WFMPre? and CURVe? commands.
CURVe?, DATa:SOUrce, WFMPre?
WFMPre? (Query Only)
Returns waveform transmission and formatting parameters for the
waveform specified by the DATa:SOUrce command.
If the waveform specified by the DATa:SOUrce command is not
displayed, the oscilloscope returns only the waveform transmission
parameters (BYT_Nr, BIT_Nr, ENCdg, BN_Fmt, BYT_Or).
Waveform
WFMPre?
The format of the response when the DATa:SOUrce waveform is
activated is:
BYT_NR <NR1>;BIT_NR <NR1>;ENCDG { ASC | BIN };
BN_FMT { RI | RP };BYT_OR { LSB | MSB };NR_PT <NR1>;
WFID <QSTRING>;PT_FMT {ENV | Y};XINCR <NR3>;
PT_OFF <NR1>;XZERO <NR3>;XUNIT<QSTRING>;YMULT <NR3>; YZERO
<NR3>;YOFF <NR3>;YUNIT <QSTRING>
WAVFrm?
Group
Syntax
Returns
Related Commands
Group
Syntax
Returns
Related Commands
