Tektronix TDS2004C

Replaceable Parts
Parts Lists and E xploded Views
The following tables show the module-level exploded views of the TDS2000C
oscilloscopes. Following each exploded view is the list of components, indexed
by the numbers in the figure.
Table 8-2: Replaceable parts list, 2-channel models
Figure
and
index
no.
Tektronix
part no.
Serial
no.
effective
Serial
no.
discont’d Qty. Name and description
8-1
2-CHANNEL MODELS
-1 850-0156-00 1
FRONT CASE
ASSY; COVER, W/FEET; TDS2001C, TDS2002C, TDS2012C, TDS2022C
-2 366-0863-00 1
ASSEMBLY, KNOB; 0.685 DIAMETER
-3 366-0862-
00
1
ASSEMBLY, KNOB; 0.470 DIAMETER
335-2308-00 1
MARKER, I
DENTIFICATION 2CH LANGUAGE, FRENCH
335-2309-00 1
MARKER, IDENTIFICATION 2CH LANGUAGE, ITALIAN
335-2310
-00
1
MARKER, IDENTIFICATION 2CH LANGUAGE, GERMAN
335-2311-00 1
MARKER,
IDENTIFICATION 2CH LANGUAGE, SPANISH
335-2312-00 1
MARKER, IDENTIFICATION 2CH LANGUAGE, JAPANESE
335-231
3-00
1
MARKER, IDENTIFICATION 2CH LANGUAGE, PORTUGUESE
335-2314-00 1
MARKER
, IDENTIFICATION 2CH LANGUAGE, SIMPLIFIED CHINESE
335-2315-00 1
MARKER, IDENTIFICATION 2CH LANGUAGE, TRADITIONAL CHINESE
335-23
16-00
1
MARKER, IDENTIFICATION 2CH LANGUAGE, KOREAN
-4
335-2317-00 1
MARKE
R, IDENTIFICATION 2CH LANGUAGE, RUSSIAN
-5
260-2904-70 1
SWITCH, KEYPAD; ELASTOMERIC, FRONT PANEL, 2CH COLOR, BONDED
-6 211-1
272-00
9
SCREW, MACHINE; 6-32 X 0.250, PNH, STL, ZNPL, T-15 TORX DR
-7
870-0188-02 1
CIRC
UIT BD ASSY; FRONT PANEL BOARD 2CH, 389- 3835-00 WIRED
-8 441-2454-02 1
CHASSIS ASSY; 2 CHANNEL; SAFETY CONTROLLED
-9 878-
0391-70
1
CIRCUIT BD ASSY; DISPLAY ADAPTER BOARD; 389429600; BONDED
870-0560-01 1
CIR
CUIT BD ASSY; MAIN, 2 CH, 50 MHZ, TESTED & CONFIGURED, COLOR,
389-4131-00 WIRED; TDS2001C
870-0561-01 1
CIR
CUIT BD ASSY; MAIN, 2 CH, 70 MHZ, TESTED & CONFIGURED, COLOR,
389-4131-00 WIRED; TDS2002C
870-0562-01 1
CI
RCUIT BD ASSY; M AIN, 2 CH, 100 MHZ, TESTED & CONFIGURED, COLOR,
389-4131-00 WIRED; TDS2012C
-10
870-0563-01 1
CI
RCUIT BD ASSY; M AIN, 2 CH, 200 MHZ, TESTED & CONFIGURED, COLOR,
389-4131-00 WIRED; TDS2022C
-11 210-1039-00 1
W
ASHER, LOCK; 0.521 ID, INT, 0.025 THK, STEEL, ZINC FINISH
-12 220-0265-00 1
NUT, PLAIN, HEX; 0.5-28 X 0.625 HEX, BRS CD PL
-
13
2
11-1216-00
4
SCREW, PT; K-30, 3MM, PAN HEAD, T-8, COLOR
-14 850-0115-70 1
D
ISPLAY ASSY; COLOR
-15 348-1525-00 1
FOOT; FRONT, SANTOPRENE, BLACK, 64 DEROMETER, TEXTURED
-
16
1
31-6417-00
1
CONTACT, ELEC; GROUNDING, 0.600 L X 0.250 W X 0.220 D, ELECTROLESS NICKEL
PLATE
-17 131-6521-00 1
CONTACT, ELEC; EMI, CLIP-ON, 0.38 L X 0.460 W (2 CONTACTS) X 0.45 HIGH,
ELECTROLESS NICKEL PLATE
TDS2000C Series Oscilloscope Service Manual 8–3
