Tektronix TDS2004C - Page 71

Adjustment Procedures
Table 5-2: Adjustment steps (cont.)
Input Setup diagram
2-ch model
step number
4-ch model
step number Signal Signal source setting
90
Sinewave Generator,
50 Ω
5kHz,1V
p-p
91
Sinewave Generator,
50 Ω
1 MHz, 100 mV
p-p
92
Sinewave Generator,
50 Ω
1MHz,1V
p-p
93
Sinewave Generator,
50 Ω
50 kHz, 1 V
p-p
94
Sinewave Generator,
50 Ω
20 MHz, 1 V
p-p
95
Sinewave Generator,
50 Ω
BWL, 25 mV
p-p
96
Sinewave Generator,
50 Ω
BWL, 50 mV
p-p
97
Sinewave Generator,
50 Ω
BWL, 100 mV
p-p
98
Sinewave Generator,
50 Ω
BWL, 250 mV
p-p
99
Sinewave Generator,
50 Ω
BWL, 500 mV
p-p
100
Sinewave Generator,
50 Ω
BWL, 1 V
p-p
101
Sinewave Generator,
50 Ω
5kHz,2.5V
p-p
102
Sinewave Generator,
50 Ω
1MHz,2.5V
p-p
103
Sinewave Generator,
50 Ω
50 kHz, 2.5 V
p-p
104
Sinewave Generator,
50 Ω
20 MHz, 2.5 V
p-p
105
Sinewave Generator,
50 Ω
BWL, 2.5 V
p-p
Ch 4 Sinewave
generator
NA
106
Sinewave Generator,
50 Ω
BWL, 5 V
p-p
TDS2000C Series Oscilloscope Service Manual 5–9
