Performance Verification
4-10
TDS1000 and TDS2000 S eries Digital Storage Oscilloscopes Service Manual
6. Set the sine wave generator output level so that CH1 indicates approximately
200 mV
p-p
so that the measured amplitude is approximately 200 mV.(The
measured amplitude can fluctuate around 200 mV.) The output level of the
sine wave generator will be approximately 400 mV.
7. Press SET LEVEL TO 50%. Adjust TRIGGER LEVEL as necessary and
then check that triggering is stable.
8. For TDS2022 and TDS2024 models, set the sine wave generator frequency
to 200 MHz.
9. For TDS2022 and TDS2024 models, set the sine wave generator output level
for CH1 to approximately 350 mV
p-p
.
10. Press SET LEVEL TO 50%. Adjust TRIGGER LEVEL as necessary and
then check that triggering is stable.
11. Change the oscilloscope setup using the following step:
Press menu button Select menu option Select setting
TRIGGER Slope Falling
12. Press SET LEVEL TO 50%. Adjust TRIGGER LEVEL as necessary and
then check that triggering is stable.
13. C hange the oscilloscope setup using the following step:
Press menu button Select menu option Select setting
TRIGGER Slope Rising
14. Disconnect the test setup.
