Tektronix TDS2022C User Manual

Replaceable Parts
Table 8-3: Repl
aceable parts list, 4-channel m odels
Figure
and
index
no.
Tektronix
part no.
Serial
no.
effective
Serial
no.
discont’d Qty. Name and description
8-2
4-CHANNEL MODELS
-1 850-0157-00 1
FRONT CASE ASSY; COVER, W/FEET; TDS2004C, TDS2014C, TDS2024C; COLOR
-2 366-0863-00 1
ASSEMBLY, KNOB; 0.685 DIAMETER
-3 366-0862-00 1
ASSEMBLY, KNOB; 0.470 DIAMETER
335-2318-00 1
MARKER, IDENTIFICATION 4CH LANGUAGE, FRENCH
335-2319-00 1
MARKER, IDENTIFICATION 4CH LANGUAGE, ITALIAN
335-2320-00 1
MARKER, IDENTIFICATION 4CH LANGUAGE, GERMAN
335-2321-00 1
MARKER, IDENTIFICATION 4CH LANGUAGE, SPANISH
335-2322-00 1
MARKER, IDENTIFICATION 4CH LANGUAGE, JAPANESE
335-2323-00 1
MARKER, IDENTIFICATION 4CH LANGUAGE, PORTUGUESE
335-2324-00 1
MARKER, IDENTIFICATION 4CH LANGUAGE, SIMPLIFIED CHINESE
335-2325-00 1
MARKER, IDENTIFICATION 4CH LANGUAGE, TRADITIONAL CHINESE
335-2326-00 1
MARKER, IDENTIFICATION 4CH LANGUAGE, KOREAN
-4
335-2327-00 1
MARKER, IDENTIFICATION 4CH LANGUAGE, RUSSIAN
-5
260-2905-70 1
SWITCH, KEYPAD; ELASTOMERIC, FRONT PANEL, 4 CH C OLOR, BONDED
-6 211-1272-00 9
SCREW, MACHINE; 6-32 X 0.250, PNH, STL, ZNPL, T- 15 TORX DR
-7
870-0190-02 1
CIRCUIT BD ASSY; FRONT PANEL BOARD 4CH, 389-3836-00 WIRED
-8 441-2455-00 1
CHASSIS ASSY; 4 CHANNEL
-9 878-0391-70 1
CIRCUIT BD ASSY; DISPLAY ADAPTER BOARD; 389429600; BONDED
870-0564-01 1
CIRCUIT BD ASSY; MAIN, 4 CH, 70 MHZ, TESTED & CONFIGURED, COLOR,
389-4132-00 WIRED; TDS2004C
870-0565-01 1
CIRCUIT BD ASSY; MAIN, 4 CH, 100 MHZ, TESTED & CONFIGURED, COLOR,
389-4132-00 WIRED; TDS2014C
-10
870-0566-01 1
CIRCUIT BD ASSY; MAIN, 4 CH, 200 MHZ, TESTED & CONFIGURED, COLOR,
389-4132-00 WIRED; TDS2024C
-11 210-1039-00 1
WASHER, LOCK; 0.521 ID, INT, 0.025 THK, STEEL, ZINC FINISH
-12 220-0265-00 1
NUT, PLAIN, HEX; 0.5-28 X 0.625 HEX, BRS, NKL PL
-13 211-1216-00 4
SCREW, PAN HEAD, PT, T8 (3MM X 1.34 X 4.3MM)
-14 850-0115–70 1
DISPLAY ASSY; COLOR
-15 348-1525-00 1
FOOT; FRONT, SANTOPRENE, BLACK, 64 DEROMETER, TEXTURED
-16 131-6417-00 1
CONTACT, ELEC; GROUNDING, 0.600 L X 0.250 W X 0.220 D, ELECTROLESS NICKEL
PLATE
-17 131-6521-00 1
CONTACT, ELEC; EMI, CLIP-ON, 0.38 L X 0.460 W (2 CONTACTS) X 0.45 HIGH,
ELECTROLESS NICKEL PLATE
TDS2000C Series Oscilloscope Service Manual 8–5

Tektronix TDS2022C Specifications

General

Bandwidth	200 MHz
Sample Rate	2 GS/s
Channels	2
Record Length	2.5 kpoints
Timebase Range	5 ns/div to 50 s/div
Math Functions	Add, Subtract, Multiply, Divide, FFT
Input Coupling	AC, DC, GND
Vertical Resolution	8 bits
Trigger Modes	Auto, Normal, Single
Memory Depth	2.5 kpoints
Display	5.7-inch color LCD
Input Impedance	1 MΩ
Trigger Types	Edge, Pulse, Video
Display Resolution	320 x 240 pixels
Connectivity	USB
Automatic Measurements	Frequency, Period, Rise Time, Fall Time
Power Supply	100-240 VAC
Time Base	5 ns to 50 s
