Specifications
Table 1-11: Limit testing system characteristics (cont.)
Characteristic Description
Vertical Limit The vertical limit in vertical divisions.
0~1000 mdiv
Horizontal Limit The horizontal limit in horizontal divisions.
0~500 mdiv.
Destination Ref Channel The location of the reference memory location that is used to store the limit test template.
RefA, RefB, RefC, RefD.
Display Template Displays or does not display a stored test template.
On, Off.
Action on Violation
Defines the actions the oscilloscope will take after a violation is detected.
Save Image: The oscilloscope will automatically save a screen image when a violation is detected.
Save Waveform: The oscilloscope will automatically save a digital copy of the source waveform when
a violation is detected.
Stop After Defines the conditions that will cause the oscilloscope to end limit testing.
Manual: Lets you stop the test by toggling the “Run/stop” choice.
Waveforms: Lets you set the numbers of waveforms to test before stopping limit testing.
Violations: Lets you set the numbers of violations to detect before stopping limit testing.
Elapsed time: Lets you set the elapsed test time in seconds to pass before stopping limit testing.
TDS2000C Series Oscilloscope Service Manual 1–15
