Performance Verification
TDS1000B and TDS2000B Series Oscilloscope Service Manual
4-3
Oscilloscope tests High limitTest resultLow limit
Channel 1 Vertical Position Accuracy, Minimum margin 0 —
Channel 2 Vertical Position Accuracy, Minimum margin 0 —
Channel 3 Vertical Position Accuracy
1
, Minimum margin 0 —
Channel 4 Vertical Position Accuracy
1
, Minimum margin 0 —
1
Channels 3 and 4 are only available on four channel oscilloscopes.
2
The bandwidth test does not have a high limit.
3
The limits vary by model. Check the procedure for the correct limits.
Performance Verification Procedures
Before beginning these procedures, two conditions must first be met:
H The oscilloscope must have been operating continuously for twenty minutes
within the operating temperature range specified.
H You must perform the Self Calibration operation described below. If the
ambient temperature changes by more than 5 °C, you must perform the Self
Calibration operation again.
The time required to complete the entire procedure is approximately one hour.
WARNING. Some procedures use hazardous voltages. To prevent electrical shock,
always set voltage source outputs to 0 V before making or changing any
interconnections.
This internal procedure is automatically performed every time the oscilloscope is
powered on. No test equipment or hookups are required. Verify that no error
messages are displayed before continuing with this procedure.
The self calibration routine lets you quickly optimize the oscilloscope signal path
for maximum measurement accuracy. You can run the routine at any time, but
you should always run the routine if the ambient temperature changes by 5 _Cor
more.
1. Disconnect any probes or cables from the channel input connectors (CH 1,
CH 2, CH 3, CH 4).
2. Push the UTILITY button and select the Do Self Cal option to start the
routine. The routine takes approximately one minute to complete.
Self Test
Self Calibration
