Bench Test Instruments and Handheld Oscilloscopes Basic Service
3
THM500 Series Specifications
The characteristics listed in this section apply under the following conditions:
H The instrument operates within the environmental conditions specified in
Table 4 on page 8, unless otherwise noted.
H The instrument warms up for at least 5 minutes.
NOTE. All specifications are warranted unless marked “typical.” Typical
characteristics are not guaranteed but are provided for the convenience of the
user.
The specifications listed for the THM565 also apply to the THM57x series
except as noted in Table 1.
Table 1: How THM565 and THM57x series products differ
57x
565
Modes
Line Test
D
Motor Test
D
Automotive preconfigured test setups
D
Vertical
Mathematics capability
D
Invert capability
D
Measurements
Voltage Measurement
D
Timing Measurement
D
Power Measurement
D
THDF Measurement
D
Automotive Measurements (preconfigured test setups)
D
Table 2: DMM specifications
550
560 565
General
Resolution 3#@4 digit (4000 count) full-scale reading except as noted
D D D
Input Impedance (Typical) VDC or VAC: 10 MW (<10 pF; <70 pF at 400 mV range)
D D D
