Tekvox TEK 1201-HD User Manual

TEK 1201-HD Presentation Switcher
TEKVOX, Inc. 3 www.tekvox.com
512.808.0845
5. IR Remote
Remote Operation
Menu/
Volume
control
area,
MUTE for
Lline and
MIC
audio.
MIC volume control area,
can work when not in
MENU mode.
Direction and OK buttons
area, these buttons are
available only in MENU
mode.
Line volume control area,
can work when not in
MENU mode.
Source select area, 12
channels for inputs,
including:
4 HDMI
4 VGA
2 C-VIDEO
1 S-Video
1 YPbPr
Output resolution select
area, five different
resolutions can be
selected, including：
720P: 1280x720
1080P: 1920x1080
XGA: 1024x768
WXGA: 1280x800
HD: 1360x768
