Operating temperature
Vac
W
nr.
°C
230
-20 +55
Vac
FM400
T10
NOIRE
T10
EDGE
500
100
NOIRE
EDGE
Max. light power W 2X 150
u.m
230
T10
FM400
Power supply
Motor supply
Max. motor power
Memorizable codes
Receiver type
mA 8Absorption on stand-by
A 2,5Maximum absorption
T10 FM400
Control unit with built-in receiver for FM400 series transmitters.
T10 NOIRE
Control unit with built-in receiver for NOIRE series transmitters.
T10 EDGE
Control unit with built-in receiver for EDGE series transmitters.
Also compatible with transmitters in the previous series TANGO (NO Rolling-Code,
NO TangoSW)
Control unit for shutters or roller shutters. Ideal for tubular motors or for
roller shutter motors. Suitable also to control two 230V lamp units.
Cable and radio control inputs.
MODELS
SPECIFICATIONS
TECHNICAL DATA
Fig. 1
1 Aerial wire
2. Jumper configurations
3. LED
4. Programming button
5. Buzzer
6 Terminal board for input of control buttons.
7 Motor-lights power supply / output terminal board
The equipment must be installed according to the principles of good
workmanship by personnel with qualifications as envisaged by current
legislation and incompliance with the standards EN12453 and EN12445
governing safety of the automation.
Recommendations for correct electrical wiring:
-The cable section must be calculated according to the length of the cables
and maximum current.
-Do not use a single multipolar cable for the motor and control power
supply. The controls must have a separate cable.
DESCRIPTION OF PARTS
ELECTRICAL CONNECTIONS AND OPERATING MODES
- Switch off power supply before making the electrical wirings.
- Failure to comply with these instructions may affect the proper
functioning of the equipment.
The company TELCOMA S.r.l. disclaims any liability for any
malfunction and / or damages resulting from failure to follow these
instructions.
