Telcoma Automations T10 FM400 User Manual

15
GB
MOTOR MODE
Connect the motor to terminals 3, 4 and 5 as follows:
- terminal 3 (F1): one motor phase
- terminal 4 (C): common
- terminal 5 (F2): the other motor phase
Then connect the 230 Vac power supply to terminals 1 and 2.
In case of reverse rotation of the motor, close jumper F3. The motor will
reverse the rotation movement.
LIGHT MODE
Two lights can be controlled by connecting them as follows:
- Light 1 between terminals 3 and 4
- Light 2 between terminals 4 and 5
Then connect the control unit power supply to terminals 1 and 2.
Programming button
no. of times to press
Function
1
to automatically memorise the OPEN-STOP-CLOSE buttons of a 20
channel radio control or a 2/4 channel radio control (in this case
buttons 1 and 2 will have the OPEN and CLOSE functions while
button 3 will have the STOP function).
2
to memorise the step-by-step function on a single button of a radio
control.
3
not used
4
to delete a code already memorised
PROGRAMMING OF TRANSMITTERS in MOTOR mode
After having selected the memorise or delete function press the transmitter
button to be memorised or deleted. The flashing Led will remain fixed for
about one second to confirm the successful outcome of the operation.
To reset the entire memory, press the programming button for about 10
seconds, until the LED lights up.
16
GB
Programming button
no. of times to press
Function
1
To memorise the OPEN button for Light 1 ON/OFF and the CLOSE
button for Light 2 ON/OFF (20 channel transmitter).
To memorise the button 1 for Light 1 ON/OFF and button 2 for Light 2
ON/OFF (2/4 channel transmitter).
2
not used
3
not used
4
to delete a code already memorised
After having selected the memorise or delete function press the transmitter
button to be memorised or deleted. The flashing Led will remain fixed for
about one second to confirm the successful outcome of the operation.
To reset the entire memory, press the programming button for about 10
seconds, until the LED lights up.
PROGRAMMING OF TRANSMITTERS in LIGHT mode
The storage of a new transmitter is possible if there is a transmitter already stored
in the control unit. The actions are:
- Press a key of a new transmitter ( not stored)
- Press a key of the old transmitter 10 times; the buzzer makes 3 rings.
- Press a key of the transmitter to be stored.
STORAGE BY RADIO
28
29
